型号	适配软管	螺纹	AG外径(mm）	AG内径(mm）	GL(mm）	H	包装 Packing
Size	Matching hose	Thread	AG external diameter (mm）	AG internal diameter (mm）			Pcs/Bag
AD10-PG7	AD10	PG7	12.3	6.5	10	23	100
AD10-M10X1		M10X1	10	6.5	10	23	100
AD10-M12X1.5		M12X1.5	12	6.5	10	25	100
AD10-M16X1.5		M16X1.5	16	6.5	10	25	100
AD11.6-PG7	AD11.6	PG7	12.3	8	10	23	100
AD11.6-M10X1		M10X1	10	8	10	23	100
AD11.6-M12X1.5		M12X1.5	12	8	10	25	100
AD13-PG9	AD13	PG9	15	10	10	25	100
AD13-M12X1.5		M12×1.5	12	7.5	11	25	100
AD13-M16×1.5		M16×1.5	16	10	10	25	100
AD13-M18×1.5		M18×1.5	16	10	10	25	100
AD13-M20×1.5		M20×1.5	16	10	10	25	100
AD15.8-PG11	AD15.8	PG11	18.4	12.5	10	27.5	100
AD15.8-PG13.5		PG13.5	20.2	12.5	10	28	100
AD15.8-M16×1.5		M16×1.5	16	11.5	10	27.5	100
AD15.8-M18×1.5		M18×1.5	18	12	10	27.5	100
AD15.8-M20×1.5		M20×1.5	20	12	10	27.5	100
AD15.8-G3/8		G3/8	16.6	12	10	28	100
AD18.5-PG13.5	AD18.5	PG13.5	20.2	14.3	12	28	50
AD18.5-M20×1.5	AD18.5	M20×1.5	20	14.3	12	28	50
AD21.2-PG16	AD21.2	PG16	22.3	17	13	32	50
AD21.2-M20×1.5		M20×1.5	20	15	13	31	50
AD21.2-M24×1.5		M24×1.5	24	17	13	31.5	50
AD21.2-M25×1.5		M25×1.5	25	17	13	27	50
AD21.2-G1/2		G1/2	20.9	15	13	31	50
AD25-M25X1.5	AD25	M25X1.5	25	20	14	30	50
AD25-G1/2	AD25	G1/2	20.9	16	13	35	50
AD28.5-PG21	AD28.5	PG21	28	23	14	34	50
AD28.5-M25×1.5		M25×1.5	25	20	14	34	50
AD28.5-M27×2.0		M27×2.0	27	20.5	14	34	50
AD28.5-M30×2.0		M30×2.0	30	22	14	34	50
AD28.5-M32×1.5		M32×1.5	32	22	14	34	50
AD28.5-G3/4		G3/4	26	20	14	35	50
AD34.5-PG29	AD34.5	PG29	36.7	29	14	36	20
AD34.5-M32×1.5		M32×1.5	32	27	14	36	20
AD34.5-M36×1.5		M36×1.5	36	29	14	36	20
AD34.5-M40×1.5		M40×1.5	40	29	14	36	20
AD34.5-G1		G1	33	27	14	36	20
AD42.5-PG36	AD42.5	PG36	46.7	36	14	38.5	10
AD42.5-M40×1.5		M40×1.5	40	34	14	38.5	10
AD42.5-M42×1.5		M42×1.5	42	36	14	38.5	10
AD42.5-M48×2.0		M48×2.0	48	36	14	38.5	10
AD54.5-PG48	AD54.5	PG48	59	53	15	40	10
AD54.5-M50×1.5		M50×1.5	50	44	15.5	39	10
AD54.5-M60×2.0		M60×2.0	60	48	15.5	39	10
AD54.5-M63X1.5		M63X1.5	63	48	15.5	39	10
AD54.5-G2		G2	59.6	48	15.5	39	10

Inquiry

* Product Name:
* Subject:
* Message:
* Contact:
* Email:
CompanyName:
* Phone:
Fax:
Address:

Thread type:	PG/M/G
Material:	Nylon PA6
Product Color:	Black,other color please inquire.
Work temperature:	from -40℃ to 100℃
